Add Fields in Trigger Output Data

This command can only be executed within the "On Event Ingestion" trigger of an event playbook. It adds new fields to "row" and "col" within "UserMappedFields" and "Fields" of the Trigger Output Data.

Reader Note

Please note that this command is only applicable within an event Playbook.

Implementation	System
Command Category	System Utility
Tags	TRIGGER DATA

Inputs

Parameter Name	Required/Optional	Description	Sample Data
Source Type	Optional	The data source from which data is being extracted.	`Trigger Output Data`
JSON Object	Optional	Key and Values to be added into Trigger Output Data	CODE `{ "sample Key":"sampleValue", "Event Type": "testType"}`

Output

Return Data

The returned result of this command. If some required parameters are not defined, this returned data could be empty. The returned result can be passed down directly to a subsequent command in playbooks.

SAMPLE DATA

JSON

{
    "Fields": [
        {
            "FieldValue": "sampleValue",
            "FieldName": "sample_Key",
            "FieldDisplayName": "sample Key",
            "FieldDistinctValue": null
        },
        {
            "FieldValue": "testType",
            "FieldName": "EventType",
            "FieldDisplayName": "Event Type",
            "FieldDistinctValue": "testType"
        }
    ],
    "UserMappedFields": {
        "row": [
            {
                "fieldName": "sample_Key",
                "value": "sampleValue",
                "displayName": "sample Key"
            },
            {
                "fieldName": "EventType",
                "value": "testType",
                "displayName": "Event Type"
            }
        ],
        "col": {
            "sample_Key": "sampleValue",
            "EventType": "testType"
        }
    }
}

Remote Command API

The D3 command API allows you to send requests to D3 SOAR to execute this utility command via REST API.

Request

POST

CODE

https://{base_url}/{api_namespace}/api/Command/addEventFieldData

Headers

Please refer to the page Webhook Configuration Guide - Authentication Method: API Keys for more details.

Request Body

JSON

{
  "Username": <Username here>,
  "Site": <Site here>,
  "CommandParams": {
    "Source Type": <Source Type here>,
    "JSON Object": <The JSON object contains fields and data here>
  }
}

Body Parameters

Parameter Name	Type	Required/Optional	Description
Username	`String`	Required	The username of your D3 SOAR account.
Site	`String`	Required	The D3 SOAR site to run the remote command.
Source Type	`Number`	Optional	The data source from which data is being extracted.
JSON Object	`JSON Object`	Optional	Tactics to set to the specified events

Sample Request

SAMPLE DATA

JSON

{
  "Username": "Admin",
  "Site": "Security Operations",
  "CommandParams": {
    "Source Type": "Trigger Output Data",
    "JSON Object": {
      "sample Key": "sampleValue",
      "Event Type": "testType"
    }
  }
}

Response

Response Fields

Field Name	Type	Description
error	`String`	The error message if the API request has failed.
returnData	`JSON Object`	The return data from the API request.

Sample Response

JSON

{
    "error": "",
    "returnData": "Successful",
    "returnData": "{
      "Fields": [
          {
              "FieldValue": "sampleValue",
              "FieldName": "sample_Key",
              "FieldDisplayName": "sample Key",
              "FieldDistinctValue": null
          },
          {
              "FieldValue": "testType",
              "FieldName": "EventType",
              "FieldDisplayName": "Event Type",
              "FieldDistinctValue": "testType"
          }
      ],
      "UserMappedFields": {
          "row": [
              {
                  "fieldName": "sample_Key",
                  "value": "sampleValue",
                  "displayName": "sample Key"
              },
              {
                  "fieldName": "EventType",
                  "value": "testType",
                  "displayName": "Event Type"
              }
          ],
          "col": {
              "sample_Key": "sampleValue",
              "EventType": "testType"
          }
      }
  }"
}
