Extract Basic Information from Email File

Last updated: Aug 07, 2024

Extracts basic information such as Sender and Recipient from an email file specified by File ID

Implementation	System
Command Category	Cyber Utility
Tags	EMAIL Condition artifact

Inputs

Parameter Name	Required/Optional	Description	Sample Data
File ID	Required	The File ID in Playbook	238

Output

Return Data

The returned result of this command. If some required parameters are not defined, this returned data could be empty. The returned result can be passed down directly to a subsequent command in playbooks.

Sample Data

JSON

Succeed

Context Data

The response data from the utility command.

Sample Data

JSON

{
    "Size ": 748,
    "Sender": "\" Zhan\" <jzhan@d3security.com>",
    "Recipient": "\" Zhan\" <jzhan@d3security.com>",
    "CCRecipient": "",
    "BCCRecipient": "",
    "ReplyTo": "",
    "Subject": "Welcome to use SOAR30",
    "ReceivedTime": "12/30/1899 12:00:00 AM",
    "SentTime ": "2020-05-27T21:45:53",
    "BodyPartCharset ": "",
    "BodyPartContentTransferEncoding ": "7bit",
    "HTMLBodyPartCharset ": "UTF-8",
    "TextBody": "Hi All,\r\n\r\nWelcome to use D3 SOAR30.\r\n\r\nThank you.\r\n\r\nD3 Security\r\n",
    "HTMLBody": "<div dir=\"ltr\">Hi All,<div><br></div><div>Welcome to use D3 SOAR30.</div><div><br></div><div>Thank you.</div><div><br></div><div>D3 Security</div></div>\r\n",
    "AttachmentsCount": "0",
    "AttachmentsNames": "Welcome to use SOAR30.eml",
    "EmailClientIp ": []
}

Remote Command API

The D3 command API allows you to send requests to D3 SOAR to execute this utility command via REST API.

Request

POST

https:/{base_url}/{api_namespace}/api/Command/ExtractBasicInfoFromEmailFile

Headers

Please refer to the page Webhook Configuration Guide - Authentication Method: API Keys for more details.

Request Body

JSON

{
  "Username": <Username here>,
  "Site": <Site here>,
  "CommandParams": {
    "File ID": <File ID here>
  }
}

Body Parameters

Parameter Name	Type	Required/Optional	Description
Username	`string`	Required	The username of your D3 SOAR account.
Site	`string`	Required	The D3 SOAR site to run the remote command.
File ID	`integer`	Required	The File ID in Playbook

Sample Request

Sample Data

JSON

{
  "Username": "Admin",
  "Site": "Security Operations",
  "CommandParams": {
    "File ID": 238
  }
}

Response

Response Fields

Field Name	Type	Description
error	`string`	The error message if the API request has failed.
returnData	`string`	The return data from the API request.
contextData	`JSON Object`	The context data from the API request.

Sample Response

JSON

{
    "error": "",
    "returnData": "Succeed",
    "contextData": {
        "Size": 748,
        "Sender": "\"Zhan\" <jzhan@d3security.com>",
        "Recipient": "\"Zhan\" <jzhan@d3security.com>",
        "CCRecipient": "",
        "BCCRecipient": "",
        "ReplyTo": "",
        "Subject": "Welcome to use SOAR30",
        "ReceivedTime": "12/30/1899 12:00:00 AM",
        "SentTime": "2020-05-27T21:45:53",
        "BodyPartCharset": "",
        "BodyPartContentTransferEncoding": "7bit",
        "HTMLBodyPartCharset": "UTF-8",
        "TextBody": "Hi All,\r\n\r\nWelcome to use D3 SOAR30.\r\n\r\nThank you.\r\n\r\nD3 Security\r\n",
        "HTMLBody": "<div dir=\"ltr\">Hi All,<div><br></div><div>Welcome to use D3 SOAR30.</div><div><br></div><div>Thank you.</div><div><br></div><div>D3 Security</div></div>\r\n",
        "AttachmentsCount": "0",
        "AttachmentsNames": "Welcome to use SOAR30.eml",
        "EmailClientIp": []
    }
}
