Update Incident Dynamic Field Values with Event Data

LAST UPDATED: AUG 29, 2024

Updates a dynamic field value of an incident with event data.

Implementation

System

Command Category

System Utility

Tags

INCIDENT INCIDENT DYNAMIC FORM

Inputs

Parameter Name

Required/Optional

Description

Sample Data

Event Field Names

Optional

The event field names.

CODE
[
    "Severity",
    "Event name",
    "Direction",
    "Device volume",
    "Source translated IP address"
]

Dynamic Section Name

Required

The name of a Section item within an incident form.

All Activities 123

Section Field Name

Required

The name of an Info Activity item within an incident form.

Text Area

Incident Number

Required

The incident number associated with the target incident.

20230206-2

Output

Key Fields

Important key-value pairs extracted from Raw Data.

SAMPLE DATA

JSON
{
  "IncidentNumber": "20230206-2",
  "ModifiedDate": "2/6/2023 5:39:38 PM",
  "ModifiedBy": "admin user"
}
Return Data

The returned result of this command. If some required parameters are not defined, this returned data could be empty. The returned result can be passed down directly to a subsequent command in playbooks.

SAMPLE DATA

JSON
Succeed
Context Data

The response data from the utility command.

SAMPLE DATA

JSON
{
    "incidentNumber": "20230206-2",
    "sectionName": "All Activities 123",
    "fieldAndValue": {
        "Text Area": "<table class='cc-table vertical-table'><tr><th>Severity</th><td>[<br>  &quot;60&quot;<br>]</td></tr><tr><th>Event name</th><td>[<br>  &quot;Bitcoin-related domain name queried by EC2 instance i-0406e39fb469745c9.&quot;,<br>  &quot;Task 40117 DT_2961 (D3MainApp.15.3) Details of 100 detections and 10 (later 100+) automation rules&quot;<br>]</td></tr><tr><th>Direction</th><td>[]</td></tr><tr><th>Device volume</th><td>[<br>  &quot;arn:aws:ec2:us-east-2:391501681688:instance/i-0406e39fb469745c9&quot;<br>]</td></tr><tr><th>Source translated IP address</th><td>[<br>  &quot;18.191.205.203, 10.10.0.116&quot;<br>]</td></tr></table>"
    },
    "modifiedDate": "2/6/2023 5:39:38 PM",
    "result": "Succeed",
    "modifiedBy": "admin user"
}

Remote Command API

The D3 command API allows you to send requests to D3 SOAR to execute this utility command via REST API.

Request

POST

CODE
https:/{base_url}/{api_namespace}/api/Command/UpdateIncidentDynamicFieldValuesWithEventData

Headers

Please refer to the page Webhook Configuration Guide - Authentication Method: API Keys for more details.

Request Body

JSON
{
  "Username": "<Username here>",
  "Site": "<Site here>",
  "CommandParams": {
    "Event Field Names": "<Event Field Names here>",
    "Dynamic Section Name": "<Dynamic Section Name here>",
    "Section Field Name": "<Section Field Name here>",
    "Incident Number": "<Incident Number here>"
  }
}

Body Parameters

Parameter Name

Type

Required/Optional

Description

Username

string

Required

The username of your D3 SOAR account.

Site

string

Required

The D3 SOAR site to run the remote command.

Event Field Names

array<string>

Optional

The event field names.

Dynamic Section Name

string

Required

The name of a Section item within an incident form.

Section Field Name

string

Required

The name of an Info Activity item within an incident form.

Incident Number

string

Required

The incident number associated with the target incident.

Sample Request

SAMPLE DATA

JSON
{
  "Username": "Admin",
  "Site": "Security Operations",
  "CommandParams": {
    "Event Field Names": [
      "Severity",
      "Event name",
      "Direction",
      "Device volume",
      "Source translated IP address"
    ],
    "Dynamic Section Name": "All Activities 123",
    "Section Field Name": "Text Area",
    "Incident Number": "20230206-2"
  }
}

Response

Response Fields

Field Name

Type

Description

error

string

The error message if the API request has failed.

keyFields

JSON Object

The key fields from the API request.

returnData

string

The return data from the API request.

contextData

JSON Object

The context data from the API request.

Sample Response

JSON
{
    "error": "",
    "keyFields": {
      "IncidentNumber": "20230206-2",
      "ModifiedDate": "2/6/2023 5:39:38 PM",
      "ModifiedBy": "admin user"
    },
    "returnData": "Succeed",
    "contextData": {
        "incidentNumber": "20230206-2",
        "sectionName": "All Activities 123",
        "fieldAndValue": {
            "Text Area": "<table class='cc-table vertical-table'><tr><th>Severity</th><td>[<br>  &quot;60&quot;<br>]</td></tr><tr><th>Event name</th><td>[<br>  &quot;Bitcoin-related domain name queried by EC2 instance i-0406e39fb469745c9.&quot;,<br>  &quot;Task 40117 DT_2961 (D3MainApp.15.3) Details of 100 detections and 10 (later 100+) automation rules&quot;<br>]</td></tr><tr><th>Direction</th><td>[]</td></tr><tr><th>Device volume</th><td>[<br>  &quot;arn:aws:ec2:us-east-2:391501681688:instance/i-0406e39fb469745c9&quot;<br>]</td></tr><tr><th>Source translated IP address</th><td>[<br>  &quot;18.191.205.203, 10.10.0.116&quot;<br>]</td></tr></table>"
        },
        "modifiedDate": "2/6/2023 5:39:38 PM",
        "result": "Succeed",
        "modifiedBy": "admin user"
    }
}
