Get Incident Timeline Entries
LAST UPDATED: SEPT 18, 2024
Retrieves all timeline entries of an incident, offering a detailed overview of the incident's chronological events and key information.
READER NOTE
This utility command is for vSOC versions 16.8 and above. Clients on earlier versions may not have access to this command. Contact D3 to obtain access.
Implementation | Python |
Command Category | System Utility |
Tags | INCIDENT TIMELINE |
Inputs
Parameter Name | Required/Optional | Description | Sample Data |
Incident Number | Required | The incident number corresponding to an incident for which the timeline entries will be retrieved. | 20200527-244 |
Filter | Optional | Filters entries by the values within any of the following fields: Summary, Note, EventType, Tactic, Technique, RiskLevel, Description and Author. | admin |
Sort Order | Optional | The order of timeline entries displayed based on the Time field. Entries can be arranged either in ascending order (earliest to latest) or descending order (latest to earliest). By default, entries are arranged in ascending order. Users can specify the sort order by typing out "ascending" or "descending," or by using "ASC" or "DESC." | Descending |
Output
Remote Command API
The D3 command API allows you to send requests to D3 SOAR to execute this utility command via REST API.
Request
POST
https:/{base_url}/{api_namespace}/api/Command/GetIncidentTimelineEntries
Headers
Please refer to the pageWebhook Configuration Guide - Authentication Method: API Keys for more details.
Request Body
{
"Username": <Username here>,
"Site": <Site here>,
"CommandParams": {
"Incident Number": <Incident Number here>,
"Filter": <Filter here>,
"Sort Order": <Sort Order here>
}
}
Body Parameters
Parameter Name | Type | Required/Optional | Description |
Username |
| Required | The username of your D3 SOAR account. |
Site |
| Required | The D3 SOAR site to run the remote command. |
Incident Number |
| Required | The incident number corresponding to an incident for which the timeline entries will be retrieved. |
Filter |
| Optional | Filters entries by the values within any of the following fields: Summary, Note, EventType, Tactic, Technique, RiskLevel, Description and Author. |
Sort Order |
| Optional | The order of timeline entries displayed based on the Time field. Entries can be arranged either in ascending order (earliest to latest) or descending order (latest to earliest). By default, entries are arranged in ascending order. Users can specify the sort order by typing out "ascending" or "descending," or by using "ASC" or "DESC." |
Sample Request
SAMPLE DATA
{
"Username": "Admin",
"Site": "Security Operations",
"CommandParams": {
"Incident Number": "20200527-244",
"Filter": "admin",
"Sort Order": "ASC"
}
}
Response
Response Fields
Field Name | Type | Description |
---|---|---|
error |
| The error message if the API request has failed. |
returnData |
| The return data from the API request. |
Sample Response
{
"error": "",
"returnData": {
"Status": "Successful",
"Data": [
{
"TimelineID": 66,
"Time": "2024-05-22 17:02:53",
"Summary": "Unauthorized data access detected",
"Note": "Multiple login attempts from unusual IP addresses",
"EventType": "Security Breach",
"Tactic": [
"Initial Access"
],
"Technique": [
"Brute Force",
"Valid Accounts"
],
"RiskLevel": "High",
"Description": "Anomalous login patterns were identified, indicating a possible brute force attack targeting admin accounts.",
"Author": "Admin User"
},
{
"TimelineID": 67,
"Time": "2024-05-22 18:15:30",
"Summary": "Malware installation attempt",
"Note": "Suspicious file download detected from phishing email",
"EventType": "Malware",
"Tactic": [
"Execution"
],
"Technique": [
"Malicious File",
"Scripting"
],
"RiskLevel": "Critical",
"Description": "A phishing email prompted the user to download a file, which was detected as malware by antivirus software.",
"Author": "Security Analyst"
},
{
"TimelineID": 68,
"Time": "2024-05-22 19:45:10",
"Summary": "Data exfiltration detected",
"Note": "Large volumes of data transferred to an external IP",
"EventType": "Data Breach",
"Tactic": [
"Exfiltration"
],
"Technique": [
"Automated Exfiltration",
"Exfiltration Over Web Service"
],
"RiskLevel": "High",
"Description": "An unusual spike in outbound data traffic was observed, indicating possible data exfiltration to an external server.",
"Author": "Incident Response Team"
}
]
}
}
