Get Data Ingestion Schedules

LAST UPDATED: SEPT 18, 2024

Retrieves information regarding the currently running data ingestion schedules, including schedule and command configurations, as well as event or incident field mappings.

READER NOTE

This utility command is targeted for versions 16.8 and above. If you are in a lower version, you may experience limitations in accessing this command. Please contact D3 for assistance in obtaining access if needed.

Implementation	Python
Command Category	System Utility
Tags	DATA INGESTION EVENT INCIENT SCHEDULE

Inputs

Parameter Name	Required/Optional	Description	Sample Data
Integration Names	Optional	The names of integrations used to filter data ingestion schedules.	CODE `[ "Integration 1", "Integration 2" ]`
Data Ingestion Types	Optional	The types of data ingestion used to filter data ingestion schedules. The options include: Event Intake Incident Intake	CODE `[ "Event Intake", "Incident Intake" ]`
Connection Names	Optional	The names of connections used to filter data ingestion schedules.	CODE `[ "Connection 1", "Connection 2" ]`
Site Names	Optional	The names of sites used to filter data ingestion schedules.	CODE `[ "Site 1", "Site 2" ]`

READER NOTE

If no input is provided, all currently running data ingestion schedules, including both event and incident schedules, will be returned.

Output

Return Data

The returned result of this command. If some required parameters are not defined, this returned data could be empty. The returned result can be passed down directly to a subsequent command in playbooks.

SAMPLE DATA

JSON

{
    "Status": "Successful",
    "Data": {
        "BasicInfo": [
            {
                "DataIngestionType": "Event Intake",
                "ConnectionId": *****
            }
        ],
        "DetailInfo": [
            {
                "IntegrationName": "IntegrationName",
                "Data IngestionType": "Event Intake",
                "ScheduledConnection": "ConnectionName1",
                "ConnectionId": *****,
                "Site": "SiteName1",
                "SiteId": *****,
                "ScheduleConfigurations": {
                    "Interval(Minutes)": 10,
                    "SendEmailNotification": 5,
                    "BufferTimeOfDataReacquire": 30,
                    "ToleranceScope(Minutes)": 20,
                    "EventPlaybook": "PlaybookName1",
                    "RunPlaybookSequentially": true,
                    "RunTTPSearch": true,
                    "RunEventAutomationRules": true
                },
                "CommandDetails": {
                    "StartTime": "2024-04-01 23:40:00",
                    "EndTime": "2024-04-02 01:00:00",
                    "queryTimeType": "updated",
                    "topN": "30",
                    "searchCondition": "{\"age\": 3}",
                    "toleranceScope": "40"
                },
                "EventFieldMappings": [
                    {
                        "EventSourceName": "Default Event Source",
                        "MainJsonPath": "$",
                        "Fields": [
                            {
                                "FieldType": "Built-in",
                                "FieldName": "Status",
                                "SystemName": "Status",
                                "SourceField": "$.fields.status.name",
                                "SourceType": "Text",
                                "ShowInIncidentSummary": false,
                                "LinkWithArtifact": true,
                                "ArtifactType": "ArtifactTypeName1",
                                "ArtifactRole": "ArtifactRoleName1"
                            }
                        ]
                    }
                ]
            }
        ]
    }
}

Remote Command API

The D3 command API allows you to send requests to D3 SOAR to execute this utility command via REST API.

Request

POST

CODE

https://{base_url}/{api_namespace}/api/Command/getDataIngestionSchedules

Headers

Please refer to the page Webhook Configuration Guide - Authentication Method: API Keys for more details.

Request Body

JSON

{
    "Username": "<Username here>",
    "Site": "<Site here>",
    "CommandParams": {
        "Integration Names": "<Integration Names here>",
        "Data Ingestion Types": "<Data Ingestion Types here>",
        "Connection Names": "<Connection Names here>",
        "Site Names": "<Site Names here>"
    }
}

Body Parameters

Parameter Name	Type	Required/Optional	Description
Username	`string`	Required	The username of your D3 SOAR account.
Site	`string`	Required	The D3 SOAR site to run the remote command.
Integration Names	`array<string>`	Optional	The names of integrations used to filter data ingestion schedules.
Data Ingestion Types	`array<string>`	Optional	The types of data ingestion used to filter data ingestion schedules. The options include: Event Intake Incident Intake
Connection Names	`array<string>`	Optional	The names of connections used to filter data ingestion schedules.
Site Names	`array<string>`	Optional	The names of sites used to filter data ingestion schedules.

Sample Request

SAMPLE DATA

JSON

{
  "Username": "Admin",
  "Site": "Security Operations",
  "CommandParams": {
    "Integration Names": [
      "Integration 1",
      "Integration 2"
    ],
    "Data Ingestion Types": [
      "Event Intake",
      "Incident Intake"
    ],
    "Connection Names": [
      "Connection 1",
      "Connection 2"
    ],
    "Site Names": [
      "Site 1",
      "Site 2"
    ]
  }
}

Response

Response Fields

Field Name	Type	Description
error	`string`	The error message if the API request has failed.
returnData	`JSON Object`	The return data from the API request.

Sample Response

JSON

{
    "error": "",
    "returnData": {
        "Status": "Successful",
        "Data": {
            "BasicInfo": [
                {
                    "DataIngestionType": "Event Intake",
                    "ConnectionId": "*****"
                }
            ],
            "DetailInfo": [
                {
                    "IntegrationName": "IntegrationName",
                    "Data IngestionType": "Event Intake",
                    "ScheduledConnection": "ConnectionName1",
                    "ConnectionId": "*****",
                    "Site": "SiteName1",
                    "SiteId": "*****",
                    "ScheduleConfigurations": {
                        "Interval(Minutes)": 10,
                        "SendEmailNotification": 5,
                        "BufferTimeOfDataReacquire": 30,
                        "ToleranceScope(Minutes)": 20,
                        "EventPlaybook": "PlaybookName1",
                        "RunPlaybookSequentially": true,
                        "RunTTPSearch": true,
                        "RunEventAutomationRules": true
                    },
                    "CommandDetails": {
                        "StartTime": "2024-04-01 23:40:00",
                        "EndTime": "2024-04-02 01:00:00",
                        "queryTimeType": "updated",
                        "topN": "30",
                        "searchCondition": "{\"age\": 3}",
                        "toleranceScope": "40"
                    },
                    "EventFieldMappings": [
                        {
                            "EventSourceName": "Default Event Source",
                            "MainJsonPath": "$",
                            "Fields": [
                                {
                                    "FieldType": "Built-in",
                                    "FieldName": "Status",
                                    "SystemName": "Status",
                                    "SourceField": "$.fields.status.name",
                                    "SourceType": "Text",
                                    "ShowInIncidentSummary": false,
                                    "LinkWithArtifact": true,
                                    "ArtifactType": "ArtifactTypeName1",
                                    "ArtifactRole": "ArtifactRoleName1"
                                }
                            ]
                        }
                    ]
                }
            ]
        }
    }
}
