Add New Artifacts in Event Playbook

Adds new artifacts of the selected type

Implementation	Python
Command Category	System Utility
Tags	`Artifact`

Inputs

Parameter Name

Required/Optional

Description

Sample Data

Source Type

Optional

NOT AVAILABLE

Trigger Output Data

Artifact Type

Optional

The type of the artifact(s). The command supports both system artifact and user-defined artifact types. System composite artifact types include: URL, User, File, ExternalEndpoint, InternalEndpoint, EmailAddress, Process, Service, Module, Driver, Signature, Certificate, Registry. System single-field artifact types include: Username, Filename, File Hash SHA256, File Hash MD5, File Hash SHA1, Process Guid, Signature Identity, Host Name, Internal Endpoint Domain Name, Internal IP, External Endpoint Domain Name, External IP, Registry Key. If this parameter is left blank, the command will automatically detect and match system composite artifact types based on the values provided in Artifact Fields.

Artifact Fields

Optional

The value of the artifact(s). For system composite artifact types, please adhere to the JSON format provided in the sample data. For single-field artifacts, an identity field must be provided along with any additional fields and reputation.

JSON

[    {        "Internal_HostName": "InternalHost",        "Internal_IPAddress": "192.168.1.1",        "Internal_HostFQDN": "internalEndpoint.com"    },    {        "External_HostName": "ExternalHost",        "External_IPAddress": "64.233.161.147",        "External_HostFQDN": "externalEndpoint.com",        "REP": {            "RiskLevel": "low"        }    },    {        "Url": "http://sampleurl.com",        "REP": {            "RiskLevel": "low"        }    },    {        "FileName": "sampleFile",        "FilePath": "samplePath",        "SHA256": "5e966c80f6122cd1c766e1c6c45fba3584940f9d99135ab7fe8fa000f859c469",        "MD5": "098f6bcd4621d373cade4e832627b4f6",        "SHA1": "a94a8fe5ccb19ba61c4c0873d391e987982fbbd3",        "REP": {            "RiskLevel": "High"        }    },    {        "UserName": "sampleUser",        "UserFQDN": " "    },    {        "EmailAddress": "sampleEmailAddress@gmail.com"    },    {        "DriverBaseAddr": "sampleDriver.com"    },    {        "ProcessGuid": "1589170327575",        "ProcessName": "powershell.exe",        "ProcessID": "21721",        "ProcessIntegrityLevel": "",        "ProcessCurrentDirectory": "",        "ProcessCommandLine": "powershell -Command $File=\\C:\\Users\\devin\\AppData\\Local\\Temp\\bbotstage.png\\;$Content=get-content $File;$Contento=[System.Text.Encoding]::ASCII.GetString([System.Convert]::FromBase64String($Content));Set-ExecutionPolicy Bypass -Scope Process -Force;IEX($Contento)",        "ProcessOS": ""    },    {        "RegistryKey": "sampleKey",        "RegistryPath": "samplePath",        "RegistryValueName": "sampleRegistryValueName",        "RegistryValueData": "sampleRegistryValueData",        "RegistryDetails": "sampleRegistryDetails"    },    {        "ServiceId": "sampleServiceId",        "ServiceName": "sampleServiceName",        "ServiceStartMode": "sampleServiceStartMode",        "ServiceStatus": "sampleServiceStatus"    },    {        "ModuleBaseAddr": "sampleModuleBaseAddr.com"    },    {        "Signature": "sampleSignature",        "SignatureID": "sampleSignatureID",        "SignatureSeverity": "Low",        "SignatureSource": "sampleSignatureSource",        "SignatureType": "sampleSignatureType"    },    {        "CertName": "sampleCertName",        "CertSerial": "sampleCertSerial"    },    {        "Identity": "customartifactid",        "REP": {            "RiskLevel": "High"        },        "Additional": {            "Action result": "action result update",            "Action result ID": "",            "Action taken": "",            "Affected Machine Name": "affected Machines Name"        }    }]

Output

Return Data

The returned result of this command. If some required parameters are not defined, this returned data could be empty. The returned result can be passed down directly to a subsequent command in playbooks.

SAMPLE DATA

JSON

{
    "InternalEndpoints": [
        {
            "AFTypeId": 1,
            "REP": null,
            "RoleId": 102,
            "HostName": "InternalHost",
            "IPAddress": "192.168.1.1",
            "IPAddresses": [
                {
                    "IPAddress": "192.168.1.1",
                    "IPType": 1
                }
            ],
            "HostFQDN": "internalEndpoint.com"
        }
    ],
    "ExternalEndpoints": [
        {
            "AFTypeId": 2,
            "REP": null,
            "RoleId": 102,
            "HostName": "ExternalHost",
            "IPAddress": "192.168.2.1",
            "IPAddresses": [
                {
                    "IPAddress": "192.168.2.1",
                    "IPType": 1
                }
            ],
            "HostFQDN": "externalEndpoint.com"
        }
    ],
    "Users": [
        {
            "AFTypeId": 5,
            "RoleId": 200,
            "REP": null,
            "UserName": "sampleUser",
            "UserFQDN": "sampleUser.com",
            "UserSID": "1"
        }
    ],
    "Processes": [
        {
            "ProcessName": "sampleProcess",
            "ProcessGuid": "D1340448-23CC-4BE8-A07F-CBB79AE5D0A7",
            "REP": {
                "RiskLevel": 1,
                "RiskResult1": null,
                "RiskResult2": null,
                "Resource": "",
                "UTCDateModified": null
            },
            "AFTypeId": 7,
            "RoleId": 400
        }
    ],
    "Registries": [
        {
            "AFTypeId": 13,
            "RoleId": 900,
            "REP": null,
            "RegistryKey": "sampleKey",
            "RegistryPath": "samplePath"
        }
    ],
    "EmailAddrs": [
        {
            "AFTypeId": 6,
            "RoleId": 1301,
            "EmailAddr": "sampleSender@gmail.com",
            "REP": null
        },
        {
            "AFTypeId": 6,
            "RoleId": 1302,
            "EmailAddr": "sampleRecipient@gmail.com",
            "REP": null
        },
        {
            "AFTypeId": 6,
            "RoleId": 1303,
            "EmailAddr": "sampleOriginalSender@gamil.com",
            "REP": null
        },
        {
            "AFTypeId": 6,
            "RoleId": 1304,
            "EmailAddr": "sampleOriginalRecipient@gmail.com",
            "REP": null
        },
        {
            "AFTypeId": 6,
            "RoleId": 1306,
            "EmailAddr": "sampleToRecipient@gmail.com",
            "REP": null
        },
        {
            "AFTypeId": 6,
            "RoleId": 1307,
            "EmailAddr": "sampleCcRecipient@gmail.com",
            "REP": null
        }
    ],
    "Files": [
        {
            "AFTypeId": 4,
            "RoleId": 300,
            "REP": null,
            "FileName": "sampleFile",
            "FilePath": "samplePath",
            "SHA256": "5e966c80f6122cd1c766e1c6c45fba3584940f9d99135ab7fe8fa000f859c469",
            "MD5": "098f6bcd4621d373cade4e832627b4f6",
            "SHA1": "a94a8fe5ccb19ba61c4c0873d391e987982fbbd3",
            "FileSignatureExists": "True",
            "FileSignatureVerified": "True",
            "FileVersion": "1.0",
            "FileDesc": "Sample file",
            "CreationUtcTime": "2022-06-16",
            "PreviousCreationUtcTime": "2022-06-15",
            "FileAccessTimeUtc": "2022-06-15",
            "FileModifyTimeUtc": "2022-06-15"
        }
    ],
    "InternalURLs": [
        {
            "AFName": "test3.com",
            "AFTypeId": 3,
            "RoleId": 1200,
            "REP": null,
            "UrlHash": "de8190c59e122d397cf759e01c83feebd1e0d94b382a44ff33df008e4395f63c",
            "Url": "test3.com"
        }
    ],
    "Drivers": [
        {
            "AFTypeId": 10,
            "RoleId": 500,
            "REP": null,
            "DriverBaseAddr": "sampleDriver.com"
        }
    ]
}

Remote Command API

The D3 command API allows you to send requests to D3 SOAR to execute this utility command via REST API.

Request

POST

CODE

https://{base_url}/{api_namespace}/api/Command/addNewArtifact

Headers

Please refer to the page Webhook Configuration Guide - Authentication Method: API Keys for more details.

Request Body

JSON

{
  "Username": <Username here>,
  "Site": <Site here>,
  "CommandParams": {
    "Source Type": <Source Type here>,
    "Artifact Type": <Artifact Type here>,
    "Artifact Fields": <Artifact Fields here>
  }
}

Body Parameters

Parameter Name	Type	Required/Optional	Description
Username	`string`	Required	The username of your D3 SOAR account.
Site	`string`	Required	The D3 SOAR site to run the remote command.
Source Type	`number`	Optional
Artifact Type	`text`	Optional	The type of the artifact(s). The command supports both system artifact and user-defined artifact types. System composite artifact types include: URL, User, File, ExternalEndpoint, InternalEndpoint, EmailAddress, Process, Service, Module, Driver, Signature, Certificate, Registry. System single-field artifact types include: Username, Filename, File Hash SHA256, File Hash MD5, File Hash SHA1, Process Guid, Signature Identity, Host Name, Internal Endpoint Domain Name, Internal IP, External Endpoint Domain Name, External IP, Registry Key. If this parameter is left blank, the command will automatically detect and match system composite artifact types based on the values provided in Artifact Fields.
Artifact Fields	`JSON Array`	Optional	The value of the artifact(s). For system composite artifact types, please adhere to the JSON format provided in the sample data. For single-field artifacts, an identity field must be provided along with any additional fields and reputation.

Sample Request

SAMPLE DATA

JSON

{
  "Username": "Admin",
  "Site": "Security Operations",
  "CommandParams": {
    "Source Type": "Trigger Output Data",
    "Artifact Type": null,
    "Artifact Fields": [
      {
        "Internal_HostName": "InternalHost",
        "Internal_IPAddress": "192.168.1.1",
        "Internal_HostFQDN": "internalEndpoint.com"
      },
      {
        "External_HostName": "ExternalHost",
        "External_IPAddress": "64.233.161.147",
        "External_HostFQDN": "externalEndpoint.com",
        "REP": {
          "RiskLevel": "low"
        }
      },
      {
        "Url": "http://sampleurl.com",
        "REP": {
          "RiskLevel": "low"
        }
      },
      {
        "FileName": "sampleFile",
        "FilePath": "samplePath",
        "SHA256": "5e966c80f6122cd1c766e1c6c45fba3584940f9d99135ab7fe8fa000f859c469",
        "MD5": "098f6bcd4621d373cade4e832627b4f6",
        "SHA1": "a94a8fe5ccb19ba61c4c0873d391e987982fbbd3",
        "REP": {
          "RiskLevel": "High"
        }
      },
      {
        "UserName": "sampleUser",
        "UserFQDN": "sampleUser.com"
      },
      {
        "EmailAddress": "sampleEmailAddress@gmail.com"
      },
      {
        "DriverBaseAddr": "sampleDriver.com"
      },
      {
        "ProcessGuid": "1589170327575",
        "ProcessName": "powershell.exe",
        "ProcessID": "21721",
        "ProcessIntegrityLevel": "",
        "ProcessCurrentDirectory": "",
        "ProcessCommandLine": "powershell -Command $File=\\C:\\Users\\devin\\AppData\\Local\\Temp\\bbotstage.png\\;$Content=get-content $File;$Contento=[System.Text.Encoding]::ASCII.GetString([System.Convert]::FromBase64String($Content));Set-ExecutionPolicy Bypass -Scope Process -Force;IEX($Contento)",
        "ProcessOS": ""
      },
      {
        "RegistryKey": "sampleKey",
        "RegistryPath": "samplePath",
        "RegistryValueName": "sampleRegistryValueName",
        "RegistryValueData": "sampleRegistryValueData",
        "RegistryDetails": "sampleRegistryDetails"
      },
      {
        "ServiceId": "sampleServiceId",
        "ServiceName": "sampleServiceName",
        "ServiceStartMode": "sampleServiceStartMode",
        "ServiceStatus": "sampleServiceStatus"
      },
      {
        "ModuleBaseAddr": "sampleModuleBaseAddr.com"
      },
      {
        "Signature": "sampleSignature",
        "SignatureID": "sampleSignatureID",
        "SignatureSeverity": "Low",
        "SignatureSource": "sampleSignatureSource",
        "SignatureType": "sampleSignatureType"
      },
      {
        "CertName": "sampleCertName",
        "CertSerial": "sampleCertSerial"
      },
      {
        "Identity": "customartifactid",
        "REP": {
          "RiskLevel": "High"
        },
        "Additional": {
          "Action result": "action result update",
          "Action result ID": "",
          "Action taken": "",
          "Affected Machine Name": "affected Machines Name"
        }
      }
    ]
  }
}

Response

Response Fields

Field Name	Type	Description
error	`string`	The error message if the API request has failed.
returnData	`string`	The return data from the API request.

Sample Response

JSON

{
    "error": "",
    "returnData": "  {
            "AFTypeId": 6,
            "RoleId": 1301,
            "EmailAddr": "sampleSender@gmail.com",
            "REP": null
        },
        {
            "AFTypeId": 6,
            "RoleId": 1302,
            "EmailAddr": "sampleRecipient@gmail.com",
            "REP": null
        },
        {
            "AFTypeId": 6,
            "RoleId": 1303,
            "EmailAddr": "sampleOriginalSender@gamil.com",
            "REP": null
        },
        {
            "AFTypeId": 6,
            "RoleId": 1304,
            "EmailAddr": "sampleOriginalRecipient@gmail.com",
            "REP": null
        },
        {
            "AFTypeId": 6,
            "RoleId": 1306,
            "EmailAddr": "sampleToRecipient@gmail.com",
            "REP": null
        },
        {
            "AFTypeId": 6,
            "RoleId": 1307,
            "EmailAddr": "sampleCcRecipient@gmail.com",
            "REP": null
        }
    ],
    "Files": [
        {
            "AFTypeId": 4,
            "RoleId": 300,
            "REP": null,
            "FileName": "sampleFile",
            "FilePath": "samplePath",
            "SHA256": "5e966c80f6122cd1c766e1c6c45fba3584940f9d99135ab7fe8fa000f859c469",
            "MD5": "098f6bcd4621d373cade4e832627b4f6",
            "SHA1": "a94a8fe5ccb19ba61c4c0873d391e987982fbbd3",
            "FileSignatureExists": "True",
            "FileSignatureVerified": "True",
            "FileVersion": "1.0",
            "FileDesc": "Sample file",
            "CreationUtcTime": "2022-06-16",
            "PreviousCreationUtcTime": "2022-06-15",
            "FileAccessTimeUtc": "2022-06-15",
            "FileModifyTimeUtc": "2022-06-15"
        }
    ],
    "InternalURLs": [
        {
            "AFName": "test3.com",
            "AFTypeId": 3,
            "RoleId": 1200,
            "REP": null,
            "UrlHash": "de8190c59e122d397cf759e01c83feebd1e0d94b382a44ff33df008e4395f63c",
            "Url": "test3.com"
        }
    ],
    "Drivers": [
        {
            "AFTypeId": 10,
            "RoleId": 500,
            "REP": null,
            "DriverBaseAddr": "sampleDriver.com"
        }
    ]
}",
}
